Powermax105 Air Plasma

Powermax105 Air Plasma

Product Details:

  • Power Source Electricity
  • Operating Type Automatic
  • Power 220-240 Volt (v)
  • Color Black
  • Warranty Yes
  • Usage & Applications Industrial
  • Click to View more
X

Powermax105 Air Plasma Price And Quantity

  • 1 Unit

Powermax105 Air Plasma Product Specifications

  • 220-240 Volt (v)
  • Electricity
  • Industrial
  • Automatic
  • Yes
  • Black

Powermax105 Air Plasma Trade Information

  • 10 Unit Per Month
  • 30 Days
  • All India

Product Description

Cutting capacity

Capacity Thickness The cutting speed
Recommended 32 mm 500 mm/min
  38 mm 250 mm/min
Separation (manual cutting) 50 mm 125 mm/min
Pierce (Drilling) * 22 mm

* Drilling specification for manual or mechanized cutting with programmable torch height control.



Maximum removal gouging

Capacity Metal removal rate Gouge profile
Common gouging 8.6 kg per hour 6.6mm L x 6.0mm W

General specifications

Input voltages

CSA

  • 200–600V, 3Ph, 50/60Hz



EC

  • 200–600V, 3Ph, 50/60Hz
  • 380–400V, 3Ph, 50/60Hz

Output in kilowatts

16.8 kW

Input current

CSA

200/208/240/480/600 V, 3F 58/56/49/25/22 A at 16.8 kW



EC

  • 230/400 V, 3F 50/29 A at 16.8 kW
  • 380/400 V, 3F 30/28 A at 16.8 kW

Output current

30–105 A

Nominal output voltage

160 VDC

Duty cycle at 104°F

CSA

  • 70% at 105A, 240V, 3Ph
  • 80% at 105 A, 480–600 V, 3P
  • 100% @ 94 A, 480–600 V, 3P
  • 100% @ 88A, 240V, 3Ph



EC

  • 80% at 105A, 400V, 3Ph
  • 100% @ 94A, 400V, 3Ph
  • 100% at 88A, 230V, 3P

Open Circuit Voltage (OCV)

CSA – 300 VDC

CE – 288 VDC

Dimensions with handles

592mm L; 274mm W; 508mm H

Weight with 7.6m torch

CSA

45.3 kg



EC

230–400 V, 42.7 kg

400V, 39.4kg

Gas supply

Clean, dry, oil-free air, or nitrogen

Ideal gas inlet pressure

7.6–8.3 bar

Minimum gas inlet pressure

5.5 bar

Recommended inlet gas flow rate range

Cut: 260 L/min at 5.9 bar

Gouging: 260 L/min at 4.8 bar

Input power cable length

3 m

Power supply type

Inverter — IGBT (insulated gate bipolar transistor)

Motor power specification

30 kW for 105 A total output

Electrical efficiency

91 %

Certifications

CSA certified for use in the Americas and Asia, excluding China

CE – for use in Europe, Australia, New Zealand, Belarus, Serbia, Ukraine and other countries where these certifications are accepted. Also RCM, Ukraine and Serbia. UKCA – Great Britain

Guarantee

Power supplies have a three-year warranty and torches have a one-year warranty
