Thermacut Plasma Power Source EX-Trafire 85 HD

Features / System

EX-Trafire 85HD

Operating Processes Operating Modes

Smoothline cutting, Drag cutting, Machine Cutting Grid cutting, Gouging, Marking

Cutting current

20"85 A

Input voltage

1 x 200-240 / 3 x 208-575 -/+ 15%

Output Amperage Range

20-65 A (1 PH)

20-85 A (3 PH)

Duty cycle

Single Phase 100% 50 A (230 VAC)

3-Phase 100% 76 A (460-575 VAC)

Rated output voltage [V] DC

140

Recommended cut capacity*

1 3/8 inch

Severance cut capacity*

2 inch

Piercing cutting capacity

1 inch

Plasma gas

Air / Nitrogen* / Argon

Torch Type Options

Hand Torch

Machine Torch

Short Machine Torch

FHT-EX105TT

Torch flow

101 l/min. at 5.2 bar

Industry (IOT) 4.0

Dimensions (L x H x W)]

22 x 15.7 x 10.2 inch

Weight [kg]

66 lbs
